ASF Baseplate & Gusset Library

50 DXF/DWG files (25 baseplates + 25 gussets) with dimension sheets, plus Tekla .tpl. AISC‑compliant, bolt hole patterns, weld prep. Covers W8–W30 columns, diagonal bracing, knee braces, end plates, shear tabs. Thickness 1/4"–1‑1/2", tolerance ±0.01".
